AUDAC Amplifier 100V Audac COM108

Product description

100V Audac COM108 amplifier, a compact and versatile amplifier, providing solutions for small and medium-sized audio systems in commercial installations.

Typical applications are background music systems in retail stores, bars, restaurants and office buildings.

The compact and simple design allows installation in any location and operation by any possible user.

The amplifier is designed using class D technology, with an output power of 80w for audio systems with constant voltage (100V and 70V) or low impedance (4 Ohm).

A switching power supply allows compatibility with a wide range of mains voltages for global compatibility.

The stereo line input allows connection of a wide range of audio sources such as media players, radio tuners, internet audio players, .

and many more.

A balanced line/microphone input allows connection of an announcement microphone, with compatibility for condenser microphones, using the integrated phantom power supply (15V).

A priority switch cancels background music when activated, and compatibility with voice file players is guaranteed by the wide gain adjustment possibility (0 dB - +50 dB).

The COM108 is a table-top device, while rack mounting in 10.5" or 19" equipment racks is possible with the help of an optionally available mounting kit (MBS310).

Features 100V Audac COM108 Amplifier: Low impedance and constant voltage output Priority audio inputs with phantom power Table or rack space installation 1 x priority deactivation contact Output connections in terminal block (4Ω, 70V, 100V) Unbalanced stereo line input 1 x microphone input Compact design Applications: Retail Bars, restaurants Public facilities Corporate spaces Specifications: Inputs Balanced microphone /Sensitivity (1W/1m) -0 dB ~ +50 dB Balanced microphone connector /3-pin euro terminal block (pitch - 3.81 mm) Inputs Unbalanced stereo / Sensitivity (1W/1m) -4 dB ~ 20 dB Frequency response (± 3 dB) 20 Hz - 20 kHz Signal / Noise > 90 dB THD+N (@ 1 kHz) < 0.5% (1/2 rated power) Crosstalk (@ 1 kHz) > 70 dB Technology Class D Switching mode power supply Power supply Operation 100 ~ 240 V AC / 50 ~ 60 Hz Inputs Microphone Balanced Phantom Power 15 V DC Inputs Priority contact disable Outputs 4-pin Euro terminal block connector (pitch - 5.08 mm) Outputs Voltage / Impedance 100/ 70 V / 4 Ω Protection Amplifier DC short circuit Protection Amplifier Overheating Protection Amplifier Signal limiting Convection cooling Operating temperature 0° ~ 40° @ 95% Humidity Inputs Unbalanced stereo RCA connector / 3.5 mm jack RMS power @ 4 Ω 1 x 80 W Dimensions 217.5 x 43.7 x 300 mm (W x H x D) Weight 3 kg Mounting 1/2 19" / 1 HE or tabletop Construction Steel Color: Black Optional: 19" rack mount adapter
