ElectroAZ LED Pixel Digital Controller SP901E reviews
Product details
Product description
DMX512 Controller for LED Pixel Digital SP901E DMX512 decoder for controlling digital pixel LED strips, compatible with almost all LEDs with integrated circuits, controlled using one or two wires such as: WS2811, WS2812B, WS2801, SK6812, RGBW, WS2813, LPD6803, LPD8806, APA102, TM1913, UCSSM19503, DMX19503, etc.
When not using DMX signal, this device can be used with SPI signal and thus controls up to 1024 Pixels.
The controller has up to 99 dynamic variations and built-in colors, such as: Flash, Glow, Fade, Smooth, Tracking, Stream, Spread, Strobe, etc.
The speed and intensity are also adjustable.
When DMX signal is input, it can be automatically identified and can work as a decoder with DMX512 compatible interface.
All decoding channels are adjustable.
Compared with other DMX decoders that can only decode one type of LED, Alitove DMX512 decoder can decode both smart pixel addressable LEDs and 5-wire RGBWW LEDs.
The controllers can be connected in line and synchronized together.
It can be used to create a colorful ambient environment, in lighting projects such as: Advertisements, Decorations, Showcases, Clubs, Restaurants, Concert Halls, Theaters, Movie Theaters, Product Shelves, Leaving, Malls, etc.
Technical Details Model: SP901E / DMX512 Compatibility: Pixel Digital LED strip Lighting modes: 99 dynamic variations and colors 5 Control channels Working voltage: 5V-24V DC Power: 0.3W/Pixel Working mode: external controller, Arduino compatible Connection: VCC-Red, GND-Black, DAT-Blue Reverse connection protection Overload protection Material: metal Package Contents 1 x Led Pixel Digital Controller SP901E
