Product details
Product description
Wire Start Capacitor 16uF-450V This capacitor, with a plastic housing, is used in household, commercial, and industrial appliances.
The capacitor can also be used in various motors to provide power at start-up.
The capacitor is frequently used to start electric motors such as: air conditioners, refrigerator cooling fans, refrigerators, radiator fans, power motors, brushcutters, compressors, water pumps, vehicle compressors, etc.
The capacitor makes contact through two wires.
Technical Details Model: CBB60-16F Contact type: 2 wires Capacitance: 16uF Tolerance: 5% Rated voltage: 400V/450V/500V AC 400V-10000h / cl B
450V-3000h / cl C
500V-120/20% 1000h / cl D Frequency: 50-60Hz Dissipation factors: 0.002 (1KHz, 20) Operating temperature: 40~+85 or -40~+70 Flammability class: UL 94 V-2,750C (RTI) SH self-healing polypropylene dielectric Insulation resistance: 3000S Voltage Resistance (Terminal to Terminal): 2 x Rated Voltage Withstand Voltage (Terminal to Case): Minimum 2000V AC for 1 min Quality system: ISO 9001 (2008) Shape: cylinder Material: plastic Package Contents 1 x 16uF-450V Wire Start Capacitor
