Sonoff MINI-DIM Matter WiFi Smart Dimmer, 0-100% LED Control, White, Flush-Mount reviews
Product details
Product description
The Sonoff MINI-DIM is an ultra-compact flush-mounted smart dimmer that upgrades conventional lighting into a modern smart-home system.
It enables remote ON/OFF control and smooth brightness adjustment from 0 to 100%, while supporting schedules, timers, scenes, automation and voice commands.
With Matter over 2.4 GHz WiFi, the MINI-DIM can integrate with popular smart-home platforms such as Apple Home, Google Home, Alexa, Samsung SmartThings and Home Assistant.
It is also compatible with the eWeLink app, allowing you to control your lighting remotely, adjust brightness, create schedules and monitor energy consumption.
The dimmer provides smooth, flicker-free operation and features automatic calibration to adapt the dimming range to the connected lamp.
This helps reduce dead zones, flickering and unwanted buzzing.
Local LAN control enables fast operation within the local network, even when internet access is unavailable.
The device is compatible with a wide range of dimmable lighting: - Dimmable LED lamps up to 200 VA - Incandescent and halogen lamps up to 400 W - Dimmable electronic transformers up to 200 W The compact 45 × 39.4 × 16.8 mm housing is designed for installation behind a conventional wall switch in a standard flush-mounted electrical box.
The module can be operated using a traditional wall switch or wirelessly through the app and compatible voice assistants.
A neutral wire is required for installation.
Safety features include overheating protection, overvoltage protection and an integrated NTC temperature sensor.
The flame-retardant PC housing complies with V-0 fire-resistance requirements, while CE and RoHS certifications confirm compliance with applicable European standards.
Key features: - Matter-compatible smart WiFi dimmer - Smooth brightness adjustment from 0 to 100% - Remote ON/OFF and brightness control - Compatibility with Apple Home, Google Home, Alexa, SmartThings, Home Assistant and eWeLink - 2.4 GHz WiFi connectivity - Voice control support - Local LAN control - Energy consumption monitoring - Automatic brightness calibration - Schedules, timers, scenes and automations - OTA firmware updates - Compatible with traditional and wireless wall switches - Compact flush-mounted design - Overheating and overvoltage protection - Neutral wire required Technical specifications: - Brand: Sonoff - Model: MINI-DIM - Product type: Flush-mounted smart dimmer - Communication standard: Matter over WiFi - Wireless standard: IEEE 802.11 b/g/n, 2.4 GHz - Controller: ESP32-C3 - Supply voltage: 220–240 V AC - Frequency: 50 Hz - Maximum resistive load: 400 W - Maximum LED load: 200 VA - Dimming range: 0–100% - Energy monitoring: Yes - Voice control: Yes - Local LAN control: Yes - Housing material: Flame-retardant PC plastic - Colour: White - Installation location: Indoor - Dimensions: 45 × 39.4 × 16.8 mm - Weight: 24.5 g - Operating temperature: -10°C to 40°C - Operating humidity: 5–95% RH, non-condensing - Recommended wire size: 18–16 AWG copper - Neutral wire: Required The package includes: - Sonoff MINI-DIM smart dimmer - User manual Installation should be carried out by a qualified person in accordance with applicable electrical regulations.
