VOLT POLSKA VOLT solar charge controller SOL 30 A LCD
-25%
(incl. VAT)
Shipped from: Romania
Trendyol's commitments
Easy and free return in 30 days.
Highlighted features:
VOLT POLSKA VOLT solar charge controller SOL 30 A LCD reviews
Product details
Product description
Solar controller (SOL PWM 30A 2xUSB regulator) for controlling the operation of autonomous photovoltaic systems.
The device provides the correct charging current characteristics for the battery(ies), additionally securing them against too deep discharges or overcharging.
SOL PWM solar controllers can be used for installations with solar panels and 12 or 24V batteries.
Features: Automatic recognition and switching of 12/24V input voltage Easy-to-read LCD display and interface controlled by 2 buttons on the housing Three-phase PWM (Pulse Width Modulation) efficient load Checking the battery charge level with the possibility of resetting the memory at night (application for example for street lighting) Over-load, short circuit, overvoltage, undervoltage, battery overcharge/discharge, reverse polarity protection 2 built-in USB slots Technical data: System voltage: 12/24V Maximum solar panel voltage: 50V Own working current: ≤15mA Maximum charging current: 30A LVD: 10.7V 9V.
.12Vx2 24V LVR: 12.6V / 11V.
.13.5Vx2 24V Backup voltage: 13.6V / 13V.
.15Vx2 24V Overload protection: 16.5Vx2 for 24V Reverse polarity protection: yes Charging mode: PWM Temperature compensation: -24mV/C for 12V installation
x2 for 24V Working temperature: -35°C to +60°C Wiring cross-section: 28-10AWG dimensions: 187x98x50mm Weight: 370g USB: 2x built-in USB 5V / 2A port
Additional info
- EU Responsible details are here.
- A maximum of 5 units of this product can be ordered. Trendyol reserves the right to cancel orders over 5 units.
- Sold and fulfilled by .
- Barcode No: 5903293765470
