adidas Datalogic QW2100 Imager Single Line USB Handheld Wired Barcode Scanner

Important information

in the adidas brand, the phrase 1/3 refers to the size itself, and the phrase 1/2 refers to half sizes. "for example, the phrase ""43 1/3"" represents the size ""43"", and the phrase ""42 1/2"" represents the size ""42.5""." Datalogic quickscanlite qw2100 imager barcode reader · handheld imager barcode reader · lightweight and sturdy design · scans 400 times per second · 0.1 mm (4 mil) resolution · reading distance 25 ~ 600 mm · scanning line as thin as a laser line · usb connection · ip42 standards · resistant to a drop of 1.5 meters reading performance light source 610-650 nm red led print contrast (minimum) 25% scanning speed 400 scans/second scanning angle pitch: +/- 65 °

roll (tilt): +/- 45 °

skew (yaw): +/- 70 ° Indicators (led) adjustable sound tone, datalogic 'green spot' good read feedback

good read led

good transmission resolution 0.102 mm / 4 mil (1d codes) view area 56 ° +/- 2 ° Physical height 170 mm depth 65 mm width 70 mm weight 119 gr (excluding stand) color black electrical input voltage 5vdc ± 0.5v operating current 340 ma @5vdc standby 190 ma @5vdc environmental light level 100,000 lux operating temperature 0 ° C ~ 50 ° C housing temperature -40 ° C ~ 70 ° C humidity %5 ~ %95 (non-condensation) drop resistance 1.5 meters ip standard ip42 esd protection (air discharge) 16 kv solving ability 1d linear codes gs1/databar included standard 1d linear codes postal codes australian post

British post Canadian post China post Japanese post Kix post Korea post Planet code Postnet Royal mail code (rm4scc) stacked codes ean/jan composites Gs1 databar composites Gs1, databar expanded stacked Gs1 databar stacked Gs1, databar stacked omnidirectional reading ranges scanning distances 5 miles : 2. 5 to 15. 0 cm7. 5 mils : 0 to 24. 0 cm10 mils: 0 to 35. 0 cm13 mils: 0 to 40. 0 cm20 mils: 0 to 60. 0 cm security and regulators regulatory approvals (certifications) - environmental compliance china & europe rohs compliant
