ElectroAZ 3 Pole Rapid Socket Connector - New

Product description

3 Pole Rapid Socket Connector - New The new 221-413 connector for all wire types sets new standards.

This new series is 40% smaller and easier to use than its successful predecessor, the 222 series.

The electrical installation connector allows for faster and more reliable connection of solid wires, minimizing space in junction boxes.

The console's COMPACT splicing connectors make installation much easier.

Due to its extremely small dimensions, the 221-413 connector is ideal for applications with limited space.

Installation is made much easier, while providing additional freedom for future expansions.

The transparent housing is another highlight: now you can clearly see whether the wires are connected properly and pulled out to the correct length.

The 3-wire connectors accommodate stranded cables from 0.14 to 4 mm as well as solid or fine wires from 0.2 to 4 mm (24-12 AWG) Ratings up to 32 A / 450 V and 105C allow the 221 series splice connectors to operate in ambient temperatures up to 85C (T85).

In addition, two easily accessible test ports provide easy testing conditions, even when installed.

Technical Details Model: WA-221-413 No.

of connection points: 3 Poles Wire size: 0.14 to 4 mm (24-12 AWG) Voltage: 450V Current: 32A Size: 18.6x8.3x18.7mm Material: ABS plastic Package Contents 1 x 3 Pole Rapid Socket Connector - New
